Region: Europe
Industry: Industrial
Approvals: Class II, EN 60950-1, IEC 60950-1, UL 60950-1
Compliance: Class II, EN 60950-1, IEC 60950-1, UL 60950-1
Efficiency: Level VI
Output Power: 25 W
Input Voltage: 90 VAC to 264 VAC
Connector Type: Barrel Connector
Mounting Style: Wall Mount
Load Regulation: Regulated
Center Pin Length: 12 mm
Number of Outputs: 1 Output
DC Output Connector: 2.1 mm Barrel Plug (2.1x5.5)
Connector A Polarity: Center Positive
DC Output Cord Length: 1.8 m
Output Current-Channel 1: 1.67 A
Output Voltage-Channel 1: 15 VDC
AC Plug included/required: Included
Operating Temperature Range: - 20 C to + 60 C
Maximum Operating Temperature: + 60 C
Minimum Operating Temperature: - 20 C
