CUI Inc PEM1-S24-S24-S アイソレーテッド 工場は現在この製品の注文を受け付けていません。

Width: 6 mm (0.236 in)

Height: 9.3 mm (0.366 in)

Length: 19.5 mm (0.768 in)

Industry: Industrial

Unit Weight: 2.400 g

Output Power: 1 W

Input Voltage: 21.6 V to 26.4 V

Mounting Style: Through Hole

Isolation Voltage: 3 kV

Number of Outputs: 1 Output

Input Voltage - Max: 26.4 V

Input Voltage - Min: 21.6 V

Input Voltage, Nominal: 24 V

Output Current-Channel 1: 42 mA

Output Voltage-Channel 1: 24 V

Maximum Operating Temperature: + 105 C

Minimum Operating Temperature: - 40 C
