Applicable fibers: SM(ITU-T G.652/G.657),MM(ITU-T G.651), DS(ITU-T G.653),NZDS(ITU-T G.655)
Typical Splicing loss: 0.02dB(SM), 0.01dB(MM), 0.04dB(DS), 0.04dB(NZDS)
Return loss: >60dB
Diameter of Cladding: 80 -150μm
Diameter of Coating: 160 - 900μm
Fiber Cleaved Length: 10-16mm (coating diameter< 250μm ), 16mm (coating diameter: 250-1000μm )
Auto-heating: Available
Operation Mode: Manual, Automatic
Typical splicing time: 6 seconds
Tube heating time: 16 seconds
Magnification: 250X(X or Y view), 125X(X and Y view)
Viewing Method: 2 x High resolution cameras
Display: 5.0 inch color LCD monitor
Storage of Splice Result: 4000 results
Tension test: 1.8-2.2N
Interactive Interface: GUI menu interface, easier operation
Battery capacity: 5200mAh Li-battery
Power supply: Power charging adaptor, Input: AC100-240V(50/60HZ), output: DC11-13.5V
Electrode life: More than 3000 ARC, replaced conveniently
Data Interface: USB 2.0
Operating condition: Altitude: 0-5000m, Humidity: 0-95%, Temp: -10°C～+50°C, Wind speed: max 15m/s
Dimension: 156mm(L)x148mm(W)x156mm(H)
Weight: 2.45kg (Including battery)
