Nominal Torque : 10 Nm
Linearity And Hysteresis : ≤ ± 0.20 %
Temperature Effect (1°C)::
a) on zero: ≤ ± 0.02%
b) on sensitivity: ≤ ± 0.02%
Nominal Sensitivity: 2mV/V
Sensivity Tolerance: ≤ ± 0.2%
Nominal Power Supply: 1-15V
Max. Power Supply: 18V
Input Resistance: 430 ± 20Ω
Output Resistance: 350 ± 5Ω
Insulation Resistance: >2 GΩ
Zero Balance: ≤ ± 0.5%
Limit Mechanical Values:
a) service torque: 100%
b) max. permissible torque: 150%
c) breaking torque: >300%
d) highly dynamic torque: 70%
c) nominal speed: 4000 rpm
Reference Temperature: +23°C
Working Temperature Range: -10/+70°C
Storage Temperature Range: -20/+80°C
Protection Class (En60529): IP40
Sensor Execution Material: Stainless Steel
Case Execution Material: Aluminium
Electrical Connection: Cable 3m
Process Coupling: ●(hexagonal); Quick action chuck
