Width: 10 mm
Height: 2 mm
Length: 10 mm
Gain Error: +/- 16 LSB
Input Type: Single-Ended
Resolution: 14 bit
Unit Weight: 498.600 mg
Architecture: SAR
Input Voltage: +/- 2.5 V
Sampling Rate: 350 kS/s
Interface Type: Parallel
Mounting Style: SMD/SMT
Reference Type: External, Internal
Sample and Hold: Yes
Power Consumption: 115 mW
Moisture Sensitive: Yes
Number of Channels: 4 Channel
Number of ADC Inputs: 4 Input
Number of Converters: 1 Converter
Supply Voltage - Max: 5 V
Supply Voltage - Min: 5 V
Analog Supply Voltage: 5 V
Digital Supply Voltage: 5 V
Pd - Power Dissipation: 160 mW
Operating Supply Voltage: 5 V
INL - Integral Nonlinearity: +/- 2 LSB
SNR - Signal to Noise Ratio: 86.04 dB
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
DNL - Differential Nonlinearity: +/- 1 LSB
