pH
Measurement Range: 0 – 14.0 pH
Resolution: 0.01 pH
Accuracy at 25 °C / 77 °F: ±0.01 pH
Calibration: Two point (pH 7.00 and pH 4.00 or pH 10.0)
Automatic Temperature Compensation: Yes (if conductivity/temperature probe is in same solution as pH probe)
Conductivity
Measurement Range:
0 – 50 EC
0 – 2500 TDS (EC≤500)
0 – 3500 ppm (EC>700)
Resolution:
0.1 EC /1 EC/ 10 EC
1 TDS/ 10 TDS
10 ppm
Accuracy at 25 °C / 77 °F: ±0.1 EC, ±1 CF, ±50 TDS, ±70 ppm
Calibration: Not required (factory calibrated)
Automatic Temperature Compensation: Yes
Temperature
Measurement Range: 0 – 50 °C / 32 – 122 °F
Resolution: 1 °C / 1 °F
Accuracy at 25 °C / 77 °F: ±1 °C / ±2 °F
Calibration: Not required (factory calibrated)
Operating Environment: 0 – 50 °C / 32 – 122 °F
Inline Probe (Conductivity and pH): Rated for a maximum pressure of 100 psi (7 bar)
pH: ¾” NPT fitting with a 1” adapter included
Conductivity: 1” NPT fitting
Power Source
Input: 100–240 VAC, 50–60 Hz, 5 VA
4 interchangeable plug types (USA, Euro, UK, NZ/AUS)
Output: 5 VDC 1 A
Signal Range
Indoor / Urban: 66 feet / 20 meters
Outdoor / RF line-of-sight: 164 feet / 50 meters
Frequency Band: 2.4 GHz ISM
System Requirements
Android (8.0 or later) or iOS (12 or later) mobile phone for Edenic Software.
Internet connection for remote access and data-logging.
Certifications
CE, FCC, IC
Contains Wi-Fi/Bluetooth Module
IC: 21098-ESP3WROOM1
FCC ID: 2AC7Z-ESP3WROOM1
User Manual Languages: English
Radio: Wi-Fi: 2.4 GHz (802.11 b/g/n)
Bluetooth: 5 (Low Energy)
