Filters and filter trays
Filter material: Glass fiber, quartz fiber, cellulose nitrate, Teflon
Filter encoding: Via RFID system and RFID transponders in the filter trays
Filter identification: Non-contact identification using RFID technology
Filter magazine
Number of magazine discs: 25
Number of filters per magazine disc: 15
Total filter capacity: max. 375
Potential equilization: Through consistent conductive design
Mikrobalance (optional)
Integrable models: Microbalance and ultra-microbalance manufactured by Sartorius or Mettler-Toledo (others upon request)
Readability (resolution): 0.001 mg or 0.0001 mg
Calibration weights: Integrated in the balance
Additional specifications
Cleanroom class (within the weighing chamber): 6
Interface: LAN (RJ-45)
Power supply
Power source: 230 V ± 10 %, 50 Hz
Power requirement (without chiller unit): approx. 1800 VA
Power requirement chiller: approx. 1300 VA
Dimensions
Width: 1190 mm
Height with protective hood: 1995 mm
Height of work surface: 875 mm
Depth: 930 mm
Weight (incl. balance platform): < 650 kg
Weight external chiller: < 75 kg
Climate control
Temperature regulation: Climate control unit (heating, cooling, humidification, dehumidification), with external water connection and external compressor
Humidifier unit: Evaporator as air cooler unit
Accuracy of temperature regulation: ± 0.5 K (with set value 20 … 22 °C)
Accuracy of humidity regulation: ± 2.5 % RH (with set value 45 … 50 % RH)
Accuracy of dew point regulation: ± 1 K (with set value 7.7 … 11.1 °C)
Operating conditions: 16 … 28 °C, 30 … 60 % rel. humidity
