Size & Weight: D156×W135×H149 (mm), 1.7kg (2.5kg with battery)
Applicable fibers: SM(ITU-T G.652), MM(ITU-T G.651), DS (ITU-T G.653), NZ/NZ DS(ITU-T G.655), BI(ITU-T G.657)
Fiber count: Single to 12
Cladding dia.: Single: 125µm / 160µm to 3mm by fiber holder system
Sheath dia.: Ribbon: 125µm / Ribbon fiber thickness 0.25 to 0.4mm
Cleave length: 9mm to 9.5mm
Splice mode: Total: 100 splice modes
Typical splice time: 13sec with SM FAST, 16 sec with SM AUTO
Heating mode: 20 heating modes
Typical tube heating time: 18sec SM FAST
Applicable sleeve: 25~60mm sleeve
Splice image capture: Max. 800
Splice result storage: Max. 10000
Typical splice loss: SM: 0.05dB, MM: 0.03dB, DS: 0.08dB, NZ/NZ DS: 0.08dB, BI: 0.05dB
Return loss: >>60dB
Fiber View: Two axis CMOS camera with 4.1 inch high-light color LCD
Fiber magnification: X/Y (32-100X magnification), or both X and Y simultaneously
Operating condition: Altitude: 0~3800m above sea level, Temperature: -10~+50°C, Wind: 15m/sec, Humidity: 0~95%RH
Tension test: 1.96~2.25N
Electrode life: 2000 splices
Power supply: AC100~240V, 50/60Hz
Battery parameters: 8400mAh high capacity battery, more than 240 times splicing and heating
Terminal: USB 2.0 connector for PC communication
Other features: Time-delay password against theft, ID electrode against fake
Option: GPS location system
