Technical Spec :
- Input Sensitivity : 0.6 ㎶/Digit (showing minimum guarantee); 0.12㎶/Digit (showing minimum)
- Range of zero adjust : Approx ± 50% of span adjust value
- Load cell Excitation:
+ DC 5V max 4 LOAD CELL available (350ohm):
+ DC 2.5 max 8 LOAD CELL available (350ohm):
+ DC 2.5 max 2 LOAD CELL available (120ohm):
+ Input sensitivity setting available on function:
- Temperature coefficient: Zero ± 0.5 ㎶/℃ (Typ.); Span ± 30ppm/℃ (Typ.)
- Non-Linearity: In 0.02% of Full Scale ± 1D
- Max measuring Voltage : 15mV
- Max display : ± 999999
- Sampling speed : 2000 times/sec
Display:
- Weight Display : 7segment , 6 digit, Character size : 12.7mm(H); 3 color LED display (orange, green, red)
- Status Display : 15Status mark; 3 color LED display (orange, green, red)
- Max/Min Display : 7segment , 5 digit, Character size : 9mm(H); LED (green)
External input/output:
- Analog Output: D/A: ±10V; A/A : 3.2mV/V(±10V)
- External Input : Zero , Hold, Latch, COMP ON COMP1~COM5
- External Output: RS-485(Modbus RTU); 3 pcs comparative output (MOS FET relay output)
- Power : AC85~250V (50/60hz) freevolt 20VA
- Operating Temp: . -5℃~40℃
- Operating Humidity : Less than 85%RH (without condensation)
- Size: 96(W) × 96(H) × 160(D) mm
OPTION only option available:
- OP-1: Parallel BCD output (TR)
- OP-4: RS-232C
- OP-7: DAV/DAI Analog Voltage / Current output; ±10V & 4~20mA)
- OP-8: Ethernet Interface
