External size: 650*850*1650 mm
Weight (kg): 250kg
Load-bearing glass: 20kg
Power equipment: 220V(AC) 50HZ
Table:
Marble size: 450*320mm
Glass size: 300*200mm
Campaign Range: X: 200 mm Y: 100mm
Focusing Range (Z axis): 200mm
Optical system:
V-TECH high-resolution color CCD1/3_inch 650TVL
Automatic zoom Coaxial navigation Lens magnification: 0.7-4.5X;
distance: 90mm
Video magnification: 25-230x (19 inch widescreen display); Display resolution:0.0001mm
3D images accurate auto measured software
Linear accuracy:
X,Y Linear Accuracy: 3+L/250, X-Y vector Accuracy: 3+L/200; Z≤5um (standard checking) (L means measured length, unit:mm)
Lighting system: Controllable: LED six circles eight octants (thirty-two phase) ring surface light + coaxial epi-illumination + parallel back light in the bottom
