Output:
Voltage range: 50~2000V
Voltage precision: 0.1%FS
Voltage resolution: 0.1V
Current range: 50~3000A
Current precision: 0.1%FS
Current resolution: 1A
Parameters:
Working mode: Laboratory mode/Production mode
Positive & negative gate voltages: 5~±100V
Gate voltage precision: 0.2%
Gate voltage resolution: 0.01V
Substrate temp. range: 25~200℃
Substrate temp. precision: 0.5%FS
Substrate temp. resolution: 0.1℃
Reserved Interface:
Fixture (adapter): Customize according to IGBT models
Communication:
Frequency: 50Hz±5Hz
Human-computer interface: LCD
External communication: LAN
Specifications:
Protection level: IP21 (indoor)
Dimensions: 1300mm (W) ×1850mm (H) × 900mm (D)
Ambient temperature: 25~40℃
