Sensor
Measuring Principle: Inductive
Measuring Range: 320μm
Probe Radius: 5μm
Probe Material: Diamond
Probe Touch Force: 4mN(0.4gf)
Probe Angle: 90°
Longitudinal Radius Of Guide Head: 45mm
Drive Parameters
Max Travel: 17.5mm/0.7inch
Drive Speed:
Sample Length= 0.25mm Vt=0.5mm
Sample Length= 0.8mm Vt=0.75mm/s
Sample Length= 2.5mm Vt=1mm/s
Returning Speed Vt=1.5mm/s
Indication Error: Less than 10%
Indication Variability: Less than 4%
Display Content:
Menu: Measurement Settings, System Settings, Storage Management, Calibration Settings, Bluetooth Settings, And Product Information
Parameters: ISO、DIN、ANSI、JIS; Four Standards Roughness Parameters
Graph: Filter Contour Graph And TP Curve
Reminder Information: Measurement , Menu Reminder, Error , Battery Level, And Shutdown
Contour and Filter
Contour: Filter
Filter Contour: RC; PC-RC; Gauss
Unfiltered Contour: D-P
Cut Length/Sampling Length: 0.25mm，0.8mm，2.5mm Optional
Evaluation Length: (1~5)L Optional
Roughness Parameters and Display Range:
Parameters: Display Range
Ra、Rq: 0.005μm~32μm
Rz、R3z、Ry、Rt、Rp、Rm、Rk、Rpk、Rvk: 0.02μm~320μm
Mr1、Mr2: 0~100%
S、Sm: 1mm
tp: 0~100%
Measuring Range and Resolution
Measuring Range: Resolution
±40μm: 0.02μm
±80μm: 0.04μm
±160μm: 0.04μm
Power Supply: 1 Lithium-ion Rechargeable Battery
Work Environment
Temperature: 0~40°C
Humidity: <90%RH
Transportation And Storage Environment
Temperature: -40°C~60°C
Humidity: <90%RH
Dimensions and Net Weight: 156x55x46.5xmm，About 400g
Connecting to PC: aType-C USB Cable
Standard Delivery
Main Unit: 1 pc
Sensor: 1 pc
Standard Block: 1 pc
Sensor Protection Cover: 1 pc
Instrument Case: 1 pc
Standard Charger (5V2A): 1 pc
Data Cable :1 pc
