Measurement Range: The Z Axis (Vertical): 320μm;The X axis (Horizontal): 17.5mm
Resolution Ratio The Z Axis (Vertical)
0.01μm/±20μm
0.02μm/±40μm
0.04μm/±80μm
Measurement Item
Parameter: Ra,RzRq,Rt,Rc,Rp,Rv,R3z,R3y,Rz(JIS),Ry,Rs,Rsk,Rku,Rmax- ,Rsm,Rmr,RPc,Rk,Rpk,RvkMr1,Mr2
Standard: ISO4287,ANSI B46.1,DIN4768,JISB601
Graphic: Primary Profile, Roughness Profile, Load Curves
Filter: RC,PC-RC,Gauss,D-P
The Sampling Length(lr): 0.25,0.8,2.5mm
Assessment Length(ln): ln= lr×n n=1~5
Sensor:
Principle: The Displacement Differential Inductance
Stylus: Natural Diamond, 60B Cone Angle, 2μm Tip Radius
Dynamometry: <4mN
Skid: Ruby,Longitudinal Radius 40mm
Taxiing Speed
lr=0.25, Vt=0.135mm/s
lr=0.8, Vt=0. 5mm/s
lr=2.5, Vt=1mm/s
Back, Vt=1mm/s
Accuracy: 0.001um
Indication Error: No More Than 10%
Indication Variability: No More Than 6%
Power Supply: 6000mAh Lithium Battery, Charger :DC5V
Size( L*W*H)
Display Unit: 161*80*40mm
Drive Unit: 22*26*114mm
Net Weight: About 320g
Working Environment
Temperature: -20°C~40°C,Humidity:<90%RH
Store And Transportation
Temperature: -40°C~60°C ,Humidity: <90%RH
Standard Delivery
Main Unit: 1 pc
Sensor :1 pc
Calibration Block: 1 pc
Block Bracket: 1 pc
Extension Cable: 1 pc
Touch Pen :1 pc
Charger: 1 pc
Usb Charging Cable: 1 pc
Instrument Case: 1 pc
