Basic Function
Screen Size: 5 Inch TFT LCD
Number Keys: Parameter Setting Digital Input
Coding Switch: Parameter Selection And Confirmation Function
Up, Down, Left And Right Function Keys: Parameter Setting Up And Down Selection Function
Lock Keyboard Lock Function: Prevent Accidental Modification Of Test Conditions Or Prohibit Modification Of Test Conditions
Alarm Function: Sound Alarm
Communication Interface: RS232C、RS484、USB
USB Interface: Copy, Copy And Storage Functions
Control InterfaceHANDLER(PLC)
Output Specifications
Current
Current Range: AC (3-30)A
Resolving Power: 0.01A/Step For 10A And 0.001A/Step For 10A And Below;
Accuracy: ±（2% +0.02A)
Voltage Voltage Range: AC 6V Max Open Circuit Voltage
Frequency: 50/60Hz Optional
Wave Form: Sine Wave
Ammeter
Measuring Range Of Ammeter: AC (3-30)A
Resolving Power: 0.01A/Step For 10A And 0.001A/Step For 10A And Below;
Accuracy: ±（2% +0.1A)
Resistance Meter
Measuring Range Of Resistance Meter:
0-510 M Ω, When The Output Current Is 3-10A;
0-120m Ω, When The Output Current Is 10A-30A
Resolving Power: 0.01A/Step For 10A And 0.001A/Step For 10A And Below;
Accuracy: ≦ ±（2%+1mΩ)
Timer Range:; 0-999.9S，Resolving Power：0.1S/Step，Accuracy：≦ ±50ms
Compensation Mode: Manual Or Automatic, Maximum Offset：100mΩ Max，Accuracy：≦ ±（2%+1mΩ)
Set The Upper Limit Range Of The Resistance: 0-510mΩ Or 0-600mΩ，Resolving Power：1m Ω，Accuracy：≦ ±（2% +1m Ω)
Test Time Range Setting: 0-999.9S，0 Means Continuity
Working Temperature And Humidity: 0℃-40℃，≦75%RH
Power Supply: 100V-121V，198V-242V，47.5-63Hz
Shape And Volume: 430mm×105mm×350mm
Weight: 13KG
