Sensor: analog hall sensor
Nominal width: DN 8..25
Process connection: female thread G 1/4..G 1 (further process connections available on request)
Metering range: 0.5...60 l/min for details see table "Ranges"
Pressure loss: 1.1...3.5 bar at Qmax.
Qmax.: to 80 l/min
Tolerance: ±3 % of full scale value
Pressure resistance: PN 200 bar optionally PN 500 bar
Media temperature: -20..+85 °C optionally -20..+150 °C
Ambient temperature: -20..+70 °C
Media: oils
Wiring: see section "Wiring"
Supply voltage: 18..30 V DC
Power consumption: <1 W
Analog output: 4..20 mA / load 500 W max. or 0..10 V / load min. 1 kW
Switching output: transistor output "push-pull", (resistant to short circuits, and reversal polarity protected) lout = 100 mA max.
Display (only with switching output): yellow LED (On = OK / Off = Alarm)
Ingress protection: IP 67
Electrical connection: for round plug connector M12x1, 4-pole
Materials medium-contact
Brass construction: CW614N nickelled, CW614N, 1.4310, hard ferrite, NBR
Stainless steel construction: 1.4571, 1.4404, 1.4310, hard ferrite PTFE-coated, FKM
Non-mediumcontact materials: CW614N, PPS
Weight: see table "Dimensions and weights"
Installation location
Standard: horizontal inwards flow; other installation positions are possible; the installation position affects the metering and switching range.
