Base Table Size: 500*730mm
Table Size: 560*560mm
T-Slot Size: 14mm
Column Diameter: 150mm
Main Motor: 1.5kW
Power: 380V/50Hz
Drilling Capacity: 40mm
Tapping Capacity: M24
Spindle Feeds: 0.1-0.2/2steps
Spindle Speed: 50-1450rpm
Spindle Steps: 12steps
Spindle Stroke: 155mm
Distance Between Spindle Center to Column: 350mm
Wroking Table Rotate: ±45°
Spindle Nose: MT-4
Spindle Down Travel: Auto
Distance Between Spindle to Base Table: 800mm
Cooling Motor: 40W
Standard Accessories:
Coolant system
Machine vise 150*150mm hardened jaws, grinded guideways
Working table fix handle
Key Type Drilling chuck 1-16mm B16 with key
Working lamp
Tool box
Spindle cover with switch
Mors taper MK2 and MK3
