Wheel Diameter: Φ250 mm
Motor Power: 3 kW
Wheel Speed: 1000–3500 rpm
Wheel Movement: Vertical / Horizontal / Segmented / Continuous / R-Axis Rotary Cutting (Optional)
Cut Types: Constant speed / Pulsing / Automatic speed adjustment
Vising Table Size: 280 × 300 mm
Maximum Cutting Diameter: Φ85 mm
Maximum Square Cross-Section: 85 × 250 mm
Travel Movement:
X-axis: 100 mm
Y-axis: 250 mm
Z-axis: 160 mm
R-axis: 360°
Features
1. Wheel Diameter: Φ250mm;
2. Rated power: 3kw;
3. Maximum cutting diameter: 85mm;
4. Fully automated control of X, Y, Z, and R axes. The Y-axis supports manual control, and the R-axis (rotation/angle) is an optional feature;
5. Capable of holding extra-long samples extending through the side door;
6. Supports multi-section continuous cutting on the X-axis (Raxis), enabling equal thickness (angle) cutting or cutting at any specified position;
7. Spacious worktable and cutting chamber, with a worktable size of 280x300 mm;
8. 10-inch large touchscreen;
9. Equipped with a laser alignment device;
