Accuracy : ≤ ± 0.05% F.S.
Nominal Load : 2.5t
Linearity: ≤ ±0.05% F.S.
Hysteresis: ≤ ±0.05% F.S.
Repeatability: ≤ ±0.02% F.S.
Internal Resolution: 40.000 div.
Readings Per Sec. (0 Filter): 2 (500ms)
Reference Temperature: +23°C
Temperature Nominal Range: -10/+40 °C
Service Temperature: -10/+70 °C
Storage Temperature: -20/+80 °C
Temperature Effect (10°C):
a) on zero: ≤ ±0.028% F.S.
b) on sensitivity: ≤ ±0.024% F.S.
Effect Of Transverse Load::
a) at 10% of nominal load: ≤ ±0.030% F.S.
Zero Function: ± 10% F.S.
Red Display (High Efficiency): 7 segments
Display Height: 13 mm
Recommended Power Supply: 12 Vdc
Max Supply Voltage: 15 Vdc
Max. Electrical Input: 25 mA
Power Connector: MIL PT02E10-6P
Mechanical Limit Values Referred To Nominal Load::
a) service load: 120%
b) max permissible load: 150%
c) breaking load: >300%
d) max transverse load: 50%
e) max permissible dynamic load: 75%
Displacement At Nominal Load: ∼0.06mm
Peso Weight : ∼1.60 kg
Protection Class (En 60529): IP40
Execution Material: Stainless Steel
Cable Length: 5m
Fixing Screws:
a) diameter: M8
b) resistance class: 12.9
c) tightening torque: 40 Nm
