Sensor type: Depending on detected gases available are
Metal oxide sensors,
Electrochemical sensors
Sampling method: Diffusion
Power supply: 24 VDC/AC ±20% (default) or 230 VAC (optional)
Digital interface: UART
Relay outputs: 2 relays with switch-over contact per sensor,
2 × SPDT, max 5 A, 30 VDC / 250 VAC
Alarms: Blinking LEDs, buzzers 85 dB
Enclosure: light-grey ABS plastic, wall mount, IP25
Dimensions: H123 × W201 × D55 mm
Operating conditions: 15...95 %RH
Atmospheric pressure ±10%
Non-Atex rated areas
The temperature depends on the sensor.
