Test Parameter: L, Q, C, D, R, Z
Test Frequency: 100Hz, 120Hz, 1kHz
Electric Level: 0.3Vrms
Basic Currency: 0.30%
Test Range
+ L: 1uH — 9999 H
0.1uH —999.9H
0.01uH —99.99H
+ C: 1pF — 9999uF
0.1pF — 999.9uF
0.01pF — 99.99uF
+ R,Z: 0.0001 Ω — 99.99 MΩ
+ Q: 0.0001 — 9999
+ D: 0.0001 — 9.999
+ Δ%: -9999%— 9999%
Test Speed: 3 times/Second
Equivalent Circuit: Series, Parallel
Range Mode: Automatic, Hold
Calibration: Open Circuit, Short Circuit, Sweep Frequency Clear
Test Terminal: 5 Terminals
Display Mode: Direct Reading
Comparator Function: Not Available
