Display:
Type: TFT
Size: 3.5"
Resolution: 960(H) x 240(W)
Power Output: DC12V 2A
Mobile Power: DC5V 1A
Video Signal Input:
Video Input: 1Vp-p
Type: NTSC/ PAL
Automatically identifying: Yes
OSD Menu: Yes
PTZ Control: Yes
PTZ Address Scanning: Yes
PTZ Address Preset: Yes
UTP Cable Test: Yes
Color Bar Output: Yes
RS-485 Signal Monitoring: Yes
Tracking network or TV cable in bundle of wires: Yes
Checking the correctness and quality of wire connections: -
Tracking signal transmission distance: -
Network cable length measurement: -
Low Voltage Indicator: Yes
Charging Indicator: Yes
Charging Protection: Yes
Sound on/off selectable (Volume adjustment): Yes
Phone cable tracing: Yes
Flashlight: Yes
Auto Power Off: Yes
Transmitter Powered By Builtin Li-ion Rechargable Battery: Yes
Receiver Powered By 9V (6F22) x 1: -
Multimeter: Best Accuracy
DC Voltage (400mV/4V/40V/400V): ±(0.8%+5)
AC Voltage (4V/40V/400V): ±(2.5%+5)
DC Current (10A): ±(2.5%+5)
AC Current (10A): ±(3.5%+5)
Resistance (400 /4k /40k /400k /4M /40M): ±(3%+5)
Capacitance (40nF/400nF/4uF/40uF/100uF): ±(5%+5)
Diode: Yes
Continuity: Yes
Optical Power Meter:
Wavelength (nm): 850, 980, 1300, 1310, 1490, 1550, 1625
Detector type: InGaAs
Range: -70dBm~6dBm
Accuracy: ±0.3 (5%)
Resolution: 0.01
Connector Type: 2.5mm ST, SC, FC
