Worktable size (LxW): 1000x320mm
T-slot (NxWxD): 3x18x80mm
X/Y/Z axis travel: 610/330/406mm
Distance from spindle center to column: 360mm
Distance from spindle end to worktable: 150-556mm
Spindle taper: BT40
Spindle power: 5.5kw
Max.spindle speed: 6000rpm
Max.feed speed: 4m/min
Rapid feed speed (X/Y/Z): 10/10/8m/min
Tool change time(T-T): 2.5s
Positioning accuracy (X/Y/Z): ±0.015mm
Re-positioning accuracy (X/Y/Z): ±0.008mm
LxWxH: 2260x1700x2200mm
Max.loading of worktable: 400kgs
Machine weight: 3000kg
