TOB TOB-BE-6048 Battery Heavy Impact And Needling And Crushing Testing Machine (2000W)

  • 制造商: TOB
    Model: TOB-BE-6048
    来源: China
    保障: 12 month
    • 报价要求 报价要求
  • 联系
  • 价格合理详情请致电

    热线:   (+84) 966520220

    电话:  +84 (24) 62923267




Testing space: W200*H200*D200mm

Testing box dimension: W1480*D720*H2040mm

Controller dimension: W500*D500*H1200m

Source voltage: AC 380V, 50HZ

Power: 2000W

Weight: About 450kg

Falling Ball weight: 9.1kg、10kg

Falling Ball height: 610~1000mm (Digital can be set)

Bar Diameter: 15.8mm or 7.9mm (can choose)

Power test model: Electric、Free fall

Pressure range: 1KN~15KN(Standard is 13KN)

Upper platen diameter: 150mm (no less than 20cm2)

Power error range: 1%Up and down

Needing speed: 10~150mm/s (stay speed can be control)

High temperature needle: Diameter

Delay function: 0~9999 second
