Ứng dụng
Nghiên cứu môi trường
Lấy mẫu trầm tích ở độ sâu lớn hơn
Dùng cho cả ứng dụng nước ngọt và nước biển
Thông số kỹ thuật
Máy lấy mẫu rơi tự do - bộ tiêu chuẩn
Độ sâu mẫu tối đa: > 30 m
Vật liệu sản phẩm: Sắt, PVC, vật liệu khác
Vận hành bằng thanh hoặc cáp: Cáp
Thông số kỹ thuật mẫu: Bán nhiễu
Đường kính mẫu: 66 mm
Chiều dài mẫu: 999 mm
Mẫu được lưu trữ trong: Ống đựng mẫu
Thể tích mẫu: 3.5 l
Vị trí lấy mẫu: Dọc
Kích thước gói: 118 x 45 x 62 cm
Khối lượng: 47 kg
Description
The free-fall corer consists of a frame, falling weight and sampler. The sampler is especially designed to take samples at greater depths (>30 metres). By using a hoist unit (davit) on board of a boat, the sampler is lowered in free fall. By its own weight and obtained velocity, the apparatus will penetrate the submerged soil.
Semi-disturbed samples can be obtained from the top layer of submerged sediments. The depth of penetration is partly determined by the composition of the material. If the bottom is rich of mud, penetration will reach about 80 centimetres; in more sandy material it will be about 30 centimetres. The system is fitted with a non-return valve at the top of the sampler so that no water remains floating above the sample. This ensures that the sample remains in place.
The Free-fall corer is not suitable for rocky bottoms, and unconsolidated materials will not hold.
Set contains
Free-fall frame with sample tube support system
Sample tubes with cutting shoe (10 pieces)
Please note that an installation is required for hoisting and lifting.
