Color: Black
Pitch: 2.54 mm
Height: 1.85 mm
Length: 15.2 mm
Features: Low profile, card polarization, metal-shielded cover
Card Type: microSD
Orientation: Right Angle
Unit Weight: 1 g
Current Rating: 500 mA
Mounting Style: PCB Mount
Number of Rows: 1 Row
Contact Plating: Gold
Contact Material: Copper Alloy
Housing Material: Thermoplastic (TP)
Termination Style: SMD/SMT
Number of Contacts: 8 Contact
Flammability Rating: UL 94 V-0
Insulation Resistance: 100 MOhms
Insertion - Extraction Style: Push-Push
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 25 C
