Measuring range M(n) : 0-2 Nm
Resolution Res(n): 0.002 Nm
Accuracy:
@ 23 °C (F.S.) +/- 0.5 % (+/- 1 digit):
Tk [offset] Automatic taring (Auto-Tara):
Tk [relative (F.S.)] +/- 0.02 %/K:
Measuring principle Bidirectional strain gauge with high-speed μ-Prozessor:
Operation modes :
Standard Real time value:
Peak Torque peak (drag indicator function):
Double peak Two consecutive torque peak values ( drag indicator function ):
Limit values 2 separately selectable limit values for both peaks (each with upper/lower limit):
Overload:
Max. admissible ± 20 Nm:
Max. display range 120 % (max. Tara 20 % of M(n)):
Display Type: LCD. 5-digit. 29 mm high | Status-LED switching between red/green
Interfaces:
USB USB 2.0 data communication and power supply:
Hirose Limits/switch signals. digital I/Os. trigger. power supply for external devices (requires optional cable):
Software:
FMI-Analyze Data analysis on PC:
COM-Bridge Data transmission (e. g. to CAQ-Software):
Memory Single values: Up to 1000 measuring values | Statistic function
Power supply: Internal solar-cell with storage capacitor | via USB
Temperature range Operation: 0...40 °C
Housing :
Weight: ca. g
L x W x H: 280 x 170 x 95.3 mm
Fixation : On tabletops up to 30 mm depth (two holes with threaded bolts and lock nuts on the bottom )
Max. clamping range : Ø 25 -180 mm
Protection code (without cable ) : IP42 (Protection against dripping water up to 15° tilt devices)
