Gain: 5 dBi, 7 dBi, 10 dBi
VSWR: 2.5:1
Width: 87 mm
Height: 103 mm
Length: 260 mm
IP Rating: IP67
Impedance: 50 Ohms
Technology: GPS, GNSS
Application: High Speed Trains, Locomotives, Trams, Buses, Coaches, Mass Transit Systems, Heavy Duty Machinery
Unit Weight: 420.714 g
Polarization: Vertical
Power Rating: 60 W
REACH - SVHC: Details
Mounting Style: Direct / Permanent Mount
Number of Bands: 2 Band
Center Frequency: 700 MHz, 800 MHz, 850 MHz, 900 MHz, 1474 MHz, 1575 MHz, 1602 MHz, 1700 MHz, 1800 MHz, 1900 MHz, 2100 MHz, 2600 MHz, 3400 MHz, 3600 MHz, 4000 MHz, 5200 MHz, 5800 MHz
Mechanical Style: Module
Maximum Frequency: 6 GHz
Minimum Frequency: 698 MHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM
Antenna Connector Type: N Female, TNC Female
Protocol - GPS, GLONASS: Galileo, GLONASS, GPS
Protocol - WiFi - 802.11: 802.11, WLAN, WiFi, WiMAX, WiFi 6E
Maximum Operating Temperature: + 80 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: 2G/3G/4G/5G, Cellular (NBIoT, LTE), GSM, UMTS, DCS, PCS, WCDMA, HSPA, EDGE, GPRS
