Width: 1.1 mm
Height: 1.2 mm
Length: 3 mm
Lens Shape: Rectangular
Unit Weight: 6 mg
Power Rating: 40 mW
Qualification: AEC-Q100
Viewing Angle: 120 deg
Mounting Style: SMD/SMT
Lens Dimensions: 1.7 mm x 0.7 mm
Lens Transparency: Water Clear
Illumination Color: Yellow
Luminous Intensity: 223 mcd
Moisture Sensitive: Yes
If - Forward Current: 30 mA
Vf - Forward Voltage: 2.4 V
Vr - Reverse Voltage: 12 V
Luminous Flux/Radiant Flux: 0.701 lm
Wavelength/Color Temperature: 587 nm
Maximum Operating Temperature: + 100 C
Minimum Operating Temperature: - 40 C
