Gain: 35 dB
Technology: SiGe
Mounting Style: SMD/SMT
Development Kit: ADL6337-EVALZA
Input Return Loss: 15 dB
NF - Noise Figure: 5.3 dB
Number of Channels: 1 Channel
Operating Frequency: 3.1 GHz to 1 GHz
Supply Voltage - Max: 5.25 V
Supply Voltage - Min: 4.75 V
Operating Supply Current: 460 mA
Operating Supply Voltage: 4.75 V to 5.25 V
OIP3 - Third Order Intercept: 42 dBm
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
