Gain: 14 dB
Technology: GaAs
Unit Weight: 23.025 g
Mounting Style: SMD/SMT
Test Frequency: 0 Hz to 2 GHz
Input Return Loss: 14 dB
NF - Noise Figure: 12 dB
Number of Channels: 1 Channel
Operating Frequency: 0 Hz to 6 GHz
Pd - Power Dissipation: 5.6 W
Operating Supply Current: 400 mA
Operating Supply Voltage: 12 V
P1dB - Compression Point: 30.5 dBm
OIP3 - Third Order Intercept: 43 dBm
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 55 C
