Gain: 14 dB
Technology: GaAs
Mounting Style: SMD/SMT
Test Frequency: 16 GHz to 22 GHz
Input Return Loss: 15 dB
NF - Noise Figure: 4 dB
Number of Channels: 1 Channel
Operating Frequency: 200 MHz to 22 GHz
Pd - Power Dissipation: 5.6 W
Operating Supply Current: 350 mA
Operating Supply Voltage: 10 V
P1dB - Compression Point: 28 dBm
OIP3 - Third Order Intercept: 41 dBm
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 55 C
