X-ray source
Source type: Primux 3000
X-ray generator: Up to 3 kW
Tube voltage / current: 20 kV to 60 kV / 2 mA to 50 mA
Goniometer
Configuration: Vertical θ/θ geometry
Measurement radius: 360 or 400 mm
Maximum usable angular range: -95° to 162.5° 2θ
Minimum step size: 0.0001°
2θ linearity: ≤0.01°
Maximum angular speed: 15 °/sec
Maximum angular resolution: 0.021° (FWHM of 1st LaB₆ peak)
Detectors:
Solid-state hybrid pixel detectors:
Pixos 2000 detector (0D and 1D mode)
Pixos 2000 CdTe detector (0D and 1D mode) for high-energy X-rays
Exterior dimensions (w x d x h): 1350 mm x 1160 mm x 1850 mm
Weight (not including optional accessories): 750 kg
Power supply:
3-Phase: 3/N/PE AC 400/230 V, 50…60 Hz, 25 A
1-Phase: 208…240 VAC, 50…60 Hz, 36 A
Maximum power consumption (without additional controllers for optional equipment): 5.5 kW
Cooling water supply:
Flow rate: > 3.6 L/min
Pressure: 4.5 – 6 bar
Temperature: < 25 °C
