Dew point measurement range: -80…+20°Ctd (standard type)
Temperature measurement range: -40…+100°C
Dew point accuracy: (Air or Nitrogen) -20…-80°C +/- 2°Ctd; -80… -110°C +/- 3°Ctd
Temperature accuracy: 0…+50°C +/-0.3°C(Standard); -40…0°C and +50…+100°C +/-0.5°C(Standard). Temperature accuracy requirements can be customized
Response time: 63% [90%],20C,1bar (gauge),4L/min:
-80 -> -30°Ctd 20s [40s]
-30 -> -70°Ctd 5min [20min]
Current output: 4…20 mA(3 lines) (range can be changed)
Current output resolution: 0.002 mA
Temperature drift of current output: 0.01% of span/C
Current output load: maximum 500 ohm
Digital output: RS485
Connector: 5-pin M12
Normal measurement: 16…30V/30 mA + 4-20mA Current output
Working temperature: -20…+70°C
Storage temperature: -30…+80°C
Relative humidity: 0…95 %RH
Sample flow rate: >1 L/min
pressure: 0…16 bar
Shell: stainless steel
Protection Level: IP65
Mechanical Parts Connection: ISO G 1/2”
Stainless steel mesh filter: filter grade 30-45 um
EMC: IEC 61326-1
