Max.Capacity (Tf): 35
Rated output ( mV/V): 1.0~1.5 norminal
Zero balance ( mV/V): 0.0±0.02
Combined error (%RO): 2
Repeatability (%RO): 0.1
Creep (30 min.) (%RO): 0.1
Temperature effect on
+ Zero value (%RO/10℃ ): 0.03
+ Output value (%RO/10℃ ): 0.05
Excitation
+ Recommend (V ): 10
+ Maximum ( V): 15
Resistance :
+ Input (Ω ): 430±50 / 800±50
+ Output ( Ω): 350± 3.5/ 700±7
Insulation ( ㏁): ＞2000 @50VDC
Compensated temp.range (℃): -10~+40
Operating temp, ( ℃ ): -20~+80
