Width: 1 mm
Height: 1.5 mm
Length: 3.2 mm
Lens Color: Colorless
Lens Shape: Dome
Power Rating: 250 mW
Viewing Angle: 120 deg
Mounting Style: SMD/SMT
Lens Dimensions: 2 mm x 1.02 mm
Lens Transparency: Clear
Illumination Color: RGB
Luminous Intensity: 20 mcd, 65 mcd, 85 mcd
Moisture Sensitive: Yes
If - Forward Current: 25 mA
Vf - Forward Voltage: 5 V
Wavelength/Color Temperature: 474 nm, 535 nm, 630 nm
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
