Inner Dimmensin (WxDxH) mm: 100x100x100
Outer Dimension (WxDxH) mm: 250x240x350
Type: Benchtop
Furnace structure: Alumina Ceramic Chamber, Temperature control system, Heating element, Furnace shell ,Main Electric Parts and other relative accessories
Max temperature: 1000°C
Continue Temp.: 950°C
Power Supply: 220V/1.2KW
Heating Element: High quality alloy resistance wire (HRE)
Chamber Material: High temperature polycrystal alumina ceramic fiber plate
Temp Precision: ±1°C
Thermocouple: N type
Temp controller: SHIMADEN (Japan) brand intelligent microcomputer PID controller can program 4 groups 32 segments
Electronic Parts: SCHNAIDER (France ) electronics brand
Heating rate: ≤ 25°C/min ( suggest 15-20°C/min for longer life using of furnace )
Safety protection: Overheat and Thermocouple-break Alarm
Furnace shell: High quality cold-rolled steel sheets CNC processing
Insulation: High quality thermal insulation material to ensure a good uniformity
Standard Packing: One pair of high temperature gloves , One pc crucible tong , one catalog and operation manual
Optional: Paperless recorder , Stainless steel exhaust chimney , Quartz /Alumina crucible
