Width: 22.3 mm
Height: 2.15 mm
Length: 20.3 mm
Data Rate: 1 Mb/s
Frequency: 2.4 GHz
Dimensions: 20.3 mm x 22.3 mm x 2.15 mm
Memory Size: 512 kB
Unit Weight: 1.800 g
Interface Type: I2C, SPI, UART, USB
Mounting Style: PCB Mount
Moisture Sensitive: Yes
Receiver Sensitivity: - 96 dBm
Supply Voltage - Max: 3.6 V
Supply Voltage - Min: 1.8 V
Antenna Connector Type: MHF4L
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
