Width: 6.6 mm
Height: 3.81 mm
Length: 10.16 mm
Fall Time: 1.75 us
Rise Time: 1.75 us
Output Type: PIN Photodiode
Unit Weight: 2.273 g
Mounting Style: Through Hole
Isolation Voltage: 5300 Vrms
Number of Channels: 1 Channel
If - Forward Current: 10 mA
Vf - Forward Voltage: 1.25 V
Vr - Reverse Voltage: 5 V
Current Transfer Ratio: 0.5 % to 1.1 %
Pd - Power Dissipation: 210 mW
Maximum Operating Temperature: + 100 C
Minimum Operating Temperature: - 55 C
