Protective conductor resistance: 0 … 4.000 Ω
Insulation resistance: 0 … 20.00 MΩ
Equivalent leakage current: 0 … 20.00 mA
Differential current: 0 … 20.00 mA
Touch current: 0 … 4.000 mA
Function test – Touch current (IT): 0.000 … 4.000 mA
Function test – Differential current (ID): 0.00 … 20.00 mA
Current consumption (I): 0.00 … 20.00 A
Line voltage (U): 0.0 … 250.0 V
Active power (P): 0 … 4000 W
Protective conductor test current: 200 mA DC
Insulation test voltage: 250 V / 500 V
Automatic polarity reversal: Yes
Integrated residual current protection: >20 mA shutdown
Bluetooth data interface: Yes
USB interface: Yes
Display: LCD dot matrix, backlit
Dimensions (W × H × D): 230 × 175 × 95 mm
Weight: approx. 1.3 kg
Protection rating: IP40
