Voltage measurement: 0...0.15, 0...0.5 V=, 0 ...1.5, 5, 15, 50, 150, 500 V=/~
Input resistance: 20 kΩ/V=, 4 kΩ/V~
Current measurement: 0 ... 50 μA=, 0 ... 0.5, 5, 50, 500 mA, 5 A=/~
Extended current measurement: ... 15 A=/~
Resistance measurement: 1 Ω ... 1 MΩ (4 ranges)
Capacitance: 200 mF ... 2 μF (4 ranges)
Level: -15 ... +56 dB (6 ranges)
Accuracy: class 2.5
Dimensions: 92 x 126 x 45 mm
Weight: approx. 0.25 kg without battery
Battery: 1.5 V IEC LR 6 (AA Mignon)
Dimensions: 92 x 126 x 45 mm
Weight: Approx. 0.3 kg without battery
Protection: Housing: IP 40, terminals: IP 20 per EN 60529/VDE 0470, part 1
