Sensor type / Sensor diameter: Vortex flow sensor VA40 with sensor head width across corners 40 mm and shaft Ø 21.3 mm for insertion in openings with a diameter greater than 40 mm
Sensor length: 250mm
Medium: air/ gases
Material in contact with the medium: stainless steel, sensor housing 1.4581, connection tube 1.4404, ceramics, gaskets: FKM, sensor silicone-free
Measuring range: 0.5 ... 40 m/s
Measuring uncertainty: < 1.0 % of meas. value + 0.03 m/s
Repeatability: ± 0.2 % of meas. value + 0.025 % of full scale
Permissible temperature of the medium: -20 ... +180 °C (continuous)
Max working pressure: up to 3 bar / 300 kPa above atmospheric
Ingress protection: IP68
For more details, see datasheet.
