Dimensions (L x W x H): 104.1 mm x 71.1mm x 160 mm
Scanner Weight: 147.42 g
Input Voltage: 4.4V DC – 5.5V DC
Operating Power (Charging) Bases: 2.5W (500 mA @ 5V DC)
Host System Interfaces: USB, Keyboard Wedge, RS-232, RS485 support for TGCS (IBM) 46XX
User Indicators: Good Decode LEDs, Rear View LEDs, Beeper (adjustable tone and volume), Vibration (optional)
Operating Temperature: 0°C to 50°C (32°F to 122°F)
Storage Temperature: -40°C to 70°C (-40°F to 158°F)
Electrostatic Discharge (ESD) (Scanners and Cradles): ±8 kV indirect coupling plane, ±15 kV direct air
Humidity: 0% to 95% relative humidity, non-condensing
Tumble: 2,000 0.5 m (1.6 ft) tumbles (impacts)
Drop: Engineered to withstand 50 1.8 m (6 ft) drops to concrete
Environmental Sealing: IP52
Light Levels: 0 to 100,000 lux (9,290 foot-candles)
Scan Pattern: Area Image (1280 x 800 pixel array)
Motion Tolerance: Up to 400 cm/s (157 in/s) for 13 mil UPC at optimal focus
Scan Angle: Horizontal: 48°; Vertical: 27°
Decode Capabilities: Reads standard 1D, PDF, 2D, Postal Digimarc, DOT Code, and OCR symbologies
Note: Decode capabilities dependent on configuration
