Numbers of unit power ON: 1~10
Input & Output Specification
Voltage range: 180~460VAC
Nominal voltage:
15kW : 200 / 208 / 220 / 380 / 400 / 415VAC
18kW : 380 / 400 / 415VAC
Phase/Wires: 3-phase / 3 wires
Frequency range: 45Hz ~ 65Hz
5kW / 10kW / 15kW type (at 180V 3-phase)
Maximum Current: 600A / Phase
Maximum Power: 180kVA
6kW / 12kW / 18kW type (at 340V 3-phase)
Maximum Current: 400A / Phase
Maximum Power: 216kVA
Setting Function
Nominal voltage setting
15kW : Selectable 200 / 208 / 220 / 380 / 400 / 415VAC
18kW : Selectable 380 / 400 / 415VAC
Frequency setting: Selectable 50Hz/60Hz
Input Measuring Function
Voltage (L1, L2, L3):
Range: 600V / 300V
Resolution: 0.01V
Accuracy: +/- 0.2%
Frequency
Resolution: 0.001Hz
Accuracy: +/- 0.2%
Output Measuring Function
Current (L1, L2, L3)
Range: 600A / 300A / 60A
Resolution: 0.01A
Accuracy: +/- 0.8%
General specification
Auxiliary Power Supply:
Input voltage: 180~460VAC , Optional 480VAC for 15kW model only
Frequency: 45Hz ~ 65Hz
Power consumption: <=55W
Standby power: <=30W
Environmental Condition:
Operating environment: Indoor use
Operating temperature: 0℃ ~ 50℃
Operating humidity: 30%rh ~ 80%rh (no condensation) Max 80% RH up to 30℃ , linear decrease to 50% RH at 40℃
Storage temperature: -20℃ ~ 70℃
Storage humidity: 10%rh ~ 80%rh (no condensation)
Altitude: Up to 2000m
Withstanding voltage:
Primary - Chassis: DC2500V
Primary - Secondary: DC2500V
Secondary - Chassis: DC2500V
Physical specification
Display panel: TFT LCD Touchscreen 127mm(5" 800x480 )
Dimensions (W x H x D): 440 x 176 x 849.6 mm
Weight: 40kg
Accessories
LAN cable: 2m
RS485 cable: 1pc (AWG24-2m)
