Width: 3 mm
Height: 1.11 mm
Length: 3 mm
Fall Time: 39 ns
Rise Time: 20 ns
Technology: Si
Unit Weight: 191.170 mg
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 P-Channel
Qg - Gate Charge: 20 nC
Number of Channels: 1 Channel
Transistor Polarity: P-Channel
Pd - Power Dissipation: 1.8 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 13 ns
Typical Turn-Off Delay Time: 43 ns
Id - Continuous Drain Current: 3.6 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 2.3 S
Rds On - Drain-Source Resistance: 90 mOhms
Vds - Drain-Source Breakdown Voltage: 30 V
Vgs th - Gate-Source Threshold Voltage: 1 V
