VSWR: 1.9
Width: 13.7 mm
Height: 1.5 mm
Length: 27.94 mm
Bandwidth: 5 MHz
Impedance: 50 Ohms
Technology: Planar
Wavelength: 1/4 Wave
Application: ISM, Remote Control, Alarms, Security Systems
Unit Weight: 3.560 g
Polarization: Linear
Mounting Style: PCB Mount
Electrical Type: Embedded Monopole
Number of Bands: 1 Band
Center Frequency: 315 MHz
Mechanical Style: Chip
Ground Plane Size: 38 mm x 84 mm
Maximum Frequency: 317 MHz
Minimum Frequency: 312 MHz
Termination Style: SMD/SMT
Protocol - Sub GHz: UHF
Maximum Operating Temperature: + 130 C
Minimum Operating Temperature: - 40 C
