Range of application
Determination of brinell hardness of ferrous metals, nonferrous metals and bearing alloys;
Wide application range, especially suitable for brinell hardness test of soft metal materials and small parts.
Main technical parameters
1. Measurement range: 5-650hbw.
2. Test force:
9.807, 49.03, 98.07, 153.2, 294.2, 612.9n. (1, 5, 10, 15.625, 30, 62.5 KGF)
3. Optical measurement system.
Objective: 2.5 x, 10 x.
Total magnification: 25 x, 100 x.
Measurement range: 200 mu m.
Dividing value: 0.025 mu m.
4. Appearance size and power supply.
Dimensions: 600*330*700mm.
Maximum height: 200mm.
Pressure head center to machine wall distance: 130mm.
Power supply: AC220V/50Hz;
Weight: 70 kg
