Capacity choose: 5,10,20,50,100,200,500kg optional
Test accuracy: Show value±1％
Display mode: Touched screen control
Unit switch: Kg, lb, N
Data sampling frequency: 200times/sec
Testing machine resolution: The maximum load is 1/±25000 yards, inside and outside are not classified, and the whole resolution is unchanged
Load sensor Basic configuration: pull and pressure sensors (maximum load)
Effective test width: 150mm
Effective tensile space: 800mm
Total stroke: 1100mm
Test speed range: 50-300mm/min Stepless speed regulation and 5-speed fixed speed
(special test speed can be customized according to customer
requirements)
Accuracy of displacement measurement: Within ± 1% of the value shown
Breakpoint ratio setting: 0～99％, The user can set the proper break downtime according to different materials
Test bench safety device: Up and down stroke limiting device
Overload protection: Over 10% of the maximum load, the machine is automatically protected
Fixture configuration: A set of stretching fixtures
Machine size: 550×400×1820mm
Machine weight: About 100 Kg
