Width: 11.5 mm
Height: 2.5 mm
Length: 19.5 mm
Antenna: Integrated
Protocol: BLE, Bluetooth 4.1
Data Rate: 1 Mb/s
Frequency: 2.44 GHz
Sensitivity: - 92.5 dBm
Unit Weight: 5 g
Output Power: 7.5 dBm
Interface Type: I2C, SPI, UART
Mounting Style: SMD/SMT
Frequency Range: 2.402 GHz to 2.48 GHz
Receiver Sensitivity: - 92.5 dBm
Supply Voltage - Max: 3.6 V
Supply Voltage - Min: 1.8 V
Antenna Connector Type: Integrated
Operating Supply Voltage: 1.8 V to 3.6 V
Supply Current Receiving: 16 mA
Supply Current Transmitting: 16 mA
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 30 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
