Pitch: 4.2 mm (0.165 in)
Application: Wire-to-Board, Power
Row Spacing: 4.2 mm (0.165 in)
Unit Weight: 635 mg
Housing Color: Natural
Contact Gender: Pin (Male)
Current Rating: 9 A
Mounting Angle: Straight
Mounting Style: Through Hole
Number of Rows: 2 Row
Voltage Rating: 600 V
Contact Plating: Tin
Contact Material: Tin
Housing Material: Nylon
Termination Style: Solder Pin
Flammability Rating: UL 94 V-2
Number of Positions: 2 Position
Termination Post Length: 3.5 mm (0.138 in)
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
