Pitch: 3.5 mm
Height: 8.51 mm
Length: 42 mm
Unit Weight: 6.157 g
REACH - SVHC: Details
Current Rating: 17.5 A
Mounting Angle: Vertical
Mounting Style: PCB Mount
Voltage Rating: 300 V
Wire Gauge Max: 16 AWG
Wire Gauge Min: 28 AWG
Contact Plating: Tin
Housing Material: Polyamide (PA)
Wire Orientation: Horizontal
Termination Style: Screw Clamp
Flammability Rating: UL 94 V-0
Number of Positions: 12 Position
